1.    Model: Chip Mounter for Special components DT401&CM101

Common CM module:

carrying Head(12/3) Nozzle Feeder Nozzle Changer Direct Tray；

3D Sensor 100MHz Line Camera, fixture adjustment, fixture maintenance, NG output conveyor belt；

Production capacity 25000 CPH

Multi head highspeed equipped with beam under the control of accurate recognition system；

Equipped  max. 140 items/8mm with direct tray feeder and overall exchange trolley for high efficiency；

2.     Model: High-Speed Chip Mounter CM602 & CM402

Extensive Application Range:

The highest capacity in industry CM402 0.06S/CHIP(60000cph)；

the highest capacity is 60000CHP；

the shortest time of board transport is 0.9s；

CP/CPK self-checking function to check in work；

high sorption rate for mounting components with narrow edge space; high passing rate of quality for one time；

High-Speed Mounting

extensive accuracy mounting for 50μm(Cpk≧1.0)；
several kinds of compound modes to meet the needs of manufacturing


3.    Model: Solder-paste Printer

Reliable, high-performance, flexible and simple in operation

Calibration accuracy: ±12.5μm（in 6∑）；

Printing accuracy: ±25μm （in 6∑）；

Wipe, calibration, adding solder paste and detection at the same time；

Intelligent print compensation function, improving print qualityIntelligent device built-in to provide guidance to all machines functions, applications and bug fixes；

Realize high yields and even achieve the ultra characteristics and requirements of lead-free printing.

Mpm 125 digital camera: innovative and precision optics technology ensures the superior alignment and advanced printing after detection.

Excellent cleaning effect for template

Benchmark could finish work in visual interface and intelligent guide.

Benchmark software and modules step instructions make installation and product changeovers more quickly.

Host integration welded frame structure


4.    Model: BM221 chip-mounter

Board size（mm）L50*W50~L330*W250

Speed: 0.25S/chip

Mount accuracy: ±50μm/chip（Cpk≥1）±30μm/QFP（Cpk≥1）

Number of components: 60 (double tape feeders 120); tray: 80

Component size (mm) 10603 chip~L150*W25*T15orL55*W55*T25

Board replacement time*22.5S (high-speed transfer specifications, *6)

Power three-phases AC200V、220、380、400、420、480、2.68Kva

Air pressure source: 0.43MPa、150L/min(A.N.R)

Equipment size（mm）: W1950*D2060*3*H1500mm*4

Weight: 52000KG


5.    Model: RL132 inserter

Board size（mm）：L 50 x W 50 ~ L 508 x W 381；

Insert speed:0.14s/point

Carrying quantity: 40/80(connect mode) 40 + 40(change mode)

Object element: 2.5/5.0 mm distance in standard, 7.5 mm、10 mm purchased parts resistance, electrolysis condenser, ceramic capacitor, LED, transistor, filter and resistance network.

Board replacement time: about 2s; about 4s(with room temperature 20⁰C)

Insert angle: 1⁰unit; 360⁰ direction

Power*1: three phases AC 200V, 3.5 kVA；

Air pressure source: 0.5 MPa, 80 L/min (A.N.R.)；

Equipment size: W 2 104 x D 2 183 x H 1 575 /W 3 200 x D 2 417 x H 1 575 *2；

Achieve highly productive area units

Miniaturized component supply unit;

LCD touch, simple operation.

Click and switch Japanese/ English/ Chinese, stored program more than 200

Global correspond transformer, non external transformer for 220,380,400,420 and 480V transformer inside



6.    MODEL: TAMURA

Applicable board: MAX. 300 × L330 (mm) MIN. 50 × L50 (mm)

Component height: Upper MAX 30mm Lower MIN 30mm

Chain width: 4mm

Transport height: 900 ±20mm

Power AC200V-50/60Hz-330kVA76A(at flip flop start)

District heating quantity: up 7 down 8

Color Computer gray temperature control range

Room temperature～350℃ temperature control method, PID closed-loop control + SSR drive

Temperature control precision  ±1℃ PCB MAX width 350mm

Transport direction left→right fixed rail transport mode, the front fixed conveyor speed 0～1800mm/min

Outline dimension: W1310 × L4200 × H1370(mm )weight: about 1300kg


7.    Model：AV131 inserter

High inserting speed ：0.12s /point. Expand the movement within the speed.

Provide productivity

Board size: L50 mm × W50 mm -- L508 mm × W381 mm；

Insert speed*1 0.12s/point

Equipped components number60+60+JW（JW purchased parts） 60+JW（JW purchased parts）；

Applicable parts: resistance 1/8W, 1/6W, 1/4W, 1/2W, jumper, diodes, cylindrical ceramiccapacitors

Board replacement time: 2.0s

Insert time 4 directions (0⁰, 90⁰, 180⁰and 270⁰)

Power*2 three phases AV 200V, 4Kva;

Air pressure source: 0.5MPa、150L/min(A.N.R.)；

Equipment size: W4050 mm × D1900 mm × H1590 mm *3 W2810 mm × D1910 mm × H1610 mm *3
